R911329177 (CSH01.1C-ET-ENS-EN1-NNN-L2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 24 Seconds

The R911329177 (CSH01.1C-ET-ENS-EN1-NNN-L2-S-NN-FW) is a Bosch Rexroth CSH01.1C-ET control section designed for single-axis operation within modular drive systems. It supports multi-Ethernet master communication, including SERCOS III, ProfiNet, and EtherCAT. The unit provides two analog outputs and features a primary encoder interface supporting IndraDyn, Hiperface, 1 Vpp, and TTL formats, as well as a secondary encoder HSF/RSF interface. Integrated with a Safe Torque Off module rated SIL 3/cat 3 PL e, this module is suitable for applications in machine tools and automation systems where reliable axis control and functional safety are required.

Technical Specifications

Product Type
Advanced Control Section

Control System Type
Single Axis

Field Bus System
Multi-Ethernet (ProfiNet, SERCOS III, EtherCAT)

Auxiliary Encoder Support
Encoder HSF/RSF interface (8V DC/ 18.2 Vpeak-peak)

Safety System
Safe Torque Off Optional Module (SIL 3/cat 3 PL e)

Applications
Machine tools, handling and mounting systems
