R911329307 (CSH01.3C-ET-NNN-NNN-CCD-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-ET-NNN-NNN-CCD-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329307 (CSH01.3C-ET-NNN-NNN-CCD-NN-S-NN-FW) is a control section for Bosch Rexroth drive controllers, featuring multi-Ethernet communication capability and two analog outputs. This device is not equipped with a primary encoder option and does not utilize optional modules at the X4 and X8 connection points. Indicator functionality includes two yellow and two green LEDs on the multi-Ethernet module. The unit contains Category C3 components as specified by IEC 61800-3. Handling should be performed exclusively by qualified personnel, with power switched off and the device discharged before contact, due to high surface temperatures during operation.

Technical Specifications

Product Type
Control Section

LEDs
2 yellow, 2 green

X4 and X8 Connection
None

Safety Technology
None

Handling
Limited plug-in and removal actions

Contact with Conductive Parts
Only after proper discharge

Power Consumption
Different for each optional module

Product Category
C3 as per IEC 61800-3 specifications

Surface Temperature
Higher than 60°C during operation

Input Type
Type 2 probe digital inputs

Dispatch
Worldwide

Backup Support
One year.
