R911329309 (CSH01.3C-PB-ENS-EN2-CCD-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-ENS-EN2-CCD-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329309 (CSH01.3C-PB-ENS-EN2-CCD-NN-S-NN-FW) is a Bosch Rexroth IndraDrive control section module intended for processing control signals in automation environments. It interfaces with standard control panels that feature a single-line display and a four-button keypad; these panels require connection or disconnection only when the control section is powered down, as they do not support hot plugging. The module's primary power consumption is 8.5 W, with additional consumption for optional modules: 6 W for each encoder interface, 1 W for the cross communication module, and 2 W for the Profibus master communication module. Power input is supplied via 24 V and 0 V terminal connectors on the power section. This control section provides two analog outputs, supports Profibus master communication, and accommodates various primary encoder options, including Indradyn, Hiperface, 1 Vpp, and TTL interfaces.

Technical Specifications

Product Type
Control Section

Compatible With
Standard Control Panels

Display
Single-Line

Keypad
4-Button

Hot Plug Support
No

Power Supply
24 Volt and 0 Volt at Power Section

Power Consumption - Basic Equipment
8.5 Watts

Typical Inrush Current
4 Amps

Maximum Pulse Width
100 milliseconds

Optional Module - Encoder Module
6 Watts Each (2 Installed)

Optional Module - Cross Communication Module
1 Watt

Optional Module - Profibus Master Communication Module
2 Watts
