R911329425 (CSH01.3C-ET-ENS-NNN-CCD-L2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 25 Seconds

The Bosch Rexroth R911329425 (MPN: CSH01.3C-ET-ENS-NNN-CCD-L2-S-NN-FW) is a CSH single-axis control section designed for integration in automation systems. It features expanded communication and encoder interfaces with two analog outputs and supports switching frequencies from 2 kHz to 16 kHz. The unit provides a D-sub 15-pin encoder evaluation interface compatible with 12V sin-cos and 5V-TTL encoders. Primary encoder support includes IndraDyn, Hiperface, 1 Vpp, and TTL types. Communication is enabled through a Multi-Ethernet module supporting ProfiNet, SERCOS III, and EtherCAT protocols. Safe Torque Off (STO) is implemented for functional safety. Configuration and error diagnostics are accessible via a control panel with four operation keys and a single-line display. Firmware must be ordered separately.

Technical Specifications

Product type
Bosch Rexroth Control Section

Inrush current
4A

Switching frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, 16 kHz

Encoder interface
D-sub 15 poles

Encoder supply voltage
12V

Safety feature
Safe Torque Off (STO)

Ethernet field bus systems
ProfiNet, SERCOS III, EtherCAT

Communication interface
IEEE 802.3 standard
