R911329693 (CSH01.3C-PB-EN1-NNN-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN1-NNN-CCD-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329693 (CSH01.3C-PB-EN1-NNN-CCD-S2-S-NN-FW) is a single-axis CSH control section from the Bosch Rexroth ADVANCED IndraDrive series, engineered for precise motor control and monitoring. It supports an inrush current of 4A and a pulse width up to 100ms. Integrated with a PROFIBUS interface for master communication, it offers high-speed synchronized motion and data transfer compatibility via IEEE 802.3 standards. Two analog outputs are provided. Encoder connections include support for HSF/RSF and resolver with a DC supply of 8V or AC 18.2V peak-peak. The control section operates across switching frequencies from 2 kHz to 16 kHz and is suitable for use with Safe Motion technology, delivering functional safety such as safe maximum speed and safe communication.

Technical Specifications

Type
Single-Axis Control Section

Inrush Current
4A

Maximum Pulse Width
100ms

Cross Communication Module Standard
IEEE 802.3

Communication Module Monitoring
LED

Communication Protocol
PROFIBUS

Integrated System
Safe Motion

Encoder Systems Supply Voltage
DC 8 V or AC 18.2 V peak-peak

Encoder Evaluation Interface
Resolver and HSF

Allowed Switching Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, 16 kHz

Firmware Compatibility
Yes
