R911329730 (CSH01.1C-NN-ENS-NNN-MEM-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-ENS-NNN-MEM-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth control section R911329730 (CSH01.1C-NN-ENS-NNN-MEM-L2-S-NN-FW) features a safe torque off functionality and operates with two compatible memory card types: one preloaded with firmware and one preformatted for parameter transmission. It is compliant with IEC 61131 standards and incorporates rapid probe inputs controlled by electronic switches, supporting current control cycle times of 62.5 μs and 125 μs. The device provides digital and analog input/output interfaces via X31 and X32 connectors, includes 2 analog outputs, and offers an H1 control panel interface for drive address assignment and analog output setting. The unit accommodates spring terminals for wiring, with a preference for wires without ferrules, and features a relay contact with a 10 ms pick-up and drop-out delay. The primary encoder interface supports Indradyn, Hiperface, 1 Vpp, and TTL signals, while master communication is not equipped. Typical inrush current is rated at 4 A.

Technical Specifications

Safe torque off mechanism
Yes

Probe Input Type
Rapid

Analog Inputs
IEC 61131 specifications

Inrush Current
Typical 4A

MEM Encoder Emulator Power Consumption
2W

Wiring Compatibility
Wire ends with/without ferrules

Current Control Cycle Times
62.5µs and 125µs

Switching Frequencies
Multiple

Connection Points
X31 and X32 for digital and analog inputs/outputs

Control Panel Interface
H1

Packaging
Custom military-grade

Usage
Specified Applications Only

Relay Contact Delay
10ms pickup delay, 10ms drop out delay

Mounting and Dismounting
Trained personnel only

Plug-in/Removal actions
Limited count.
