R911329783 (CSH01.1C-NN-EN2-NNN-MA1-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-EN2-NNN-MA1-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329783 (CSH01.1C-NN-EN2-NNN-MA1-S2-S-NN-FW) is a Rexroth Indramat control unit designed for integration into industrial servo systems. It provides two analog outputs and supports EnDat 2.1, 1 Vpp, and TTL primary encoder options. This controller includes a control panel for drive address assignment, position data reference setup, error memory access, and analog output configuration. It is classified as a C3 device, requires high voltage operation, and must be properly grounded. The unit can generate a leakage current up to 3.5 mA and is intended for installation at up to 1000 meters above sea level. Physical dimensions are 241 mm length, 103 mm width, and 49.5 mm thickness, with screw terminal and block connection points for electrical integration.

Technical Specifications

Design Standards
American and European standards

Dust Protection
Yes

User Interface
Control Panel

Length
241mm

Width
103mm

Thickness
49.5mm

Product Category
C3

Leakage Current
3.5 milliamperes

Connection Type
Screw Terminals

Max Installation Height
1000 meter above sea level
