R911329807 (CSH01.1C-PB-EN2-NNN-NNN-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-NNN-NNN-L2-S-NN-FW Series Image

In Stock, Ships Fast

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911329807 (CSH01.1C-PB-EN2-NNN-NNN-L2-S-NN-FW) is a control section for CSH-series drive controllers, designed to manage electric motor operations. This unit features a PROFIBUS module for master communication via a D-Sub 9-pin connector and supports connection cables from 0.08 mm² to 0.5 mm². It integrates several digital inputs and outputs, two analog outputs, and supports a single axis with Safe Torque OFF functionality. The device supports the EnDat 2.1/1 Vpp/TTL primary encoder option, utilizes both screw and spring terminal block connections, and is not compatible with the VCP01.2 comfort control panel. Isolated inputs and outputs for the 24V supply voltage are not provided in the power section.

Technical Specifications

Product Group
CSH

Line Code
1

Communication Module
PROFIBUS

Connector Type
D-Sub female 9-pin

Cable Used
0.08mm2 to 0.5mm2 stranded wire

Data Standards
EIA-RS485

Configuration
Configurable

Axes
Single

Control Panel Compatibility
Not compatible with VCP01.2

Digital Outputs and Inputs
Present

Encoder
EnDat 2.1 / 1Vpp / TTL

Relay Contact
1 Normally Open

Safety Feature
Safe Torque OFF

Terminals
Screw terminal blocks, spring terminals

Terminal Types
0V, 24V

Scope of Delivery
Global
