R911329809 (CSH01.1C-PB-ENS-EN2-MA1-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-EN2-MA1-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Indramat MPN R911329809 (CSH01.1C-PB-ENS-EN2-MA1-S2-S-NN-FW) is an industrial control unit engineered for integration within compliant automated machinery. This unit provides PROFIBUS master communication, two analog outputs, and supports primary encoder options for Indradyn, Hiperface, 1 Vpp, and TTL. The control section offers current, position, and speed control periods from 62.5 to 500 microseconds, handles 7.5W power consumption, and utilizes natural convection cooling. Key features include one standard control panel, 11 digital inputs, two touch probe functions, four digital outputs, one relay output, S2 safety option, adjustable width modulation, 4 A inrush current, a single analog input, and an RS232 serial interface. Physical dimensions are 103 mm x 241 mm x 49.5 mm, and installation is specified for operation within 1000 meters above sea level by qualified personnel.

Technical Specifications

Product Type
Control Section

Communication
PROFIBUS master

Firmware
Not included

Current Control Periods
62.5-125 microseconds

Position Control Periods
250-500 microseconds

Speed Control Periods
125-250 microseconds

Power Consumption
7.5W

Cooling System
Natural Convection

Digital Inputs
11

Inrush Current
4amps

Control Section Width Modulation Frequency
2 - 16 kHz

Pulse Width
100ms

Control Panel
Standard

Safety Option
S2 (safe motion)

Installation Limit
10,000 feet

Dimensions
103mm x 241mm x 49.5mm

SERCOS Cycle Period
1000 microseconds

Analog Inputs
1

RS232 Serial Port
1

Digital Outputs
4

Option 1 Encoder
IndraDyn/hiperface

Option 2 Encoder
EnDat2.1

Digital Inputs Option 3
7 - 11

Analog I/O Extension
Included

User Competency
Must be operated by a trained worker.
