R911329810 (CSH01.1C-PB-ENS-EN2-MD2-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-EN2-MD2-S2-S-NN-FW Series Image

In Stock, Ships in 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth control section with MPN R911329810 (CSH01.1C-PB-ENS-EN2-MD2-S2-S-NN-FW) is designed for integration within drive controllers and features two analog outputs, a PROFIBUS master communication interface using a 9-pin female D-Sub connector, and support for primary encoder options such as IndraDyn, Hiperface, 1 Vpp, and TTL. The device incorporates low input resistance digital inputs, with specific inputs sharing channels with analog signals, and utilizes separated power supply inputs and outputs. Connection options include spring or screw terminal blocks. Installation and removal must be performed by qualified personnel according to technical guidelines. Polarity reversal protection and correct supply voltage must be ensured. The module is not compatible with the VCP01.2 control panel, must not be operated underwater, and features a safety module at the X41 port for safety-related functions.

Technical Specifications

Use of Protective Diode
Yes

Interface Type
H1 interface for control panel

Communication Module
PROFIBUS module

Connection
D-Sub 9-pin female connector

Hazardous Substances
None

Connectivity
Supports spring terminals or screw terminal blocks

Operation Requirement
Should be operated inside the drive controller

Power Source
Requires separate power supply

Power Consumption
Depends on basic equipment and optional modules

Data Storage
Multimedia card in the X7 slot

Backup Support
One year

Installation
By trained personnel only

Intended Use
Not for underwater use

Delivery Method
Via reputed freight carriers

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-PB-ENS-EN2-MD2-S2-S-NN-FW.

Exchange

Want to sell your CSH01.1C-PB-ENS-EN2-MD2-S2-S-NN-FW?
