R911329847 (CSH01.1C-S3-EN2-ENS-NNN-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN2-ENS-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329847 (CSH01.1C-S3-EN2-ENS-NNN-S2-S-NN-FW) is a control section from the CSH series by Bosch Rexroth Indramat, with dimensions of 241 mm x 103 mm x 49.5 mm. Designed for applications requiring compact control such as printing, packaging machinery, and robotics, it supports SERCOS III master communication and includes both a SERCOS III and an RS232 interface. This module provides 2 analog outputs and supports EnDat 2.1/1 Vpp/TTL encoder options. It is equipped with separate ports for digital and analog I/O, a control panel interface (H1), a memory card slot (X7), and dedicated connection points for digital I/O (X31.8 and X31.9). Operation is restricted to qualified personnel. The module incorporates protection against incorrect connections or power supply polarity via a protective diode. Firmware is not included and must be ordered separately. Refer to the product documentation for detailed configuration and safety information.

Technical Specifications

Product Type
Control Section

Dimensions
241 mm x 103 mm x 49.5 mm

Interface Type
SERCOS III and serial RS232

Ports
Separate ports for digital and analog I/O

Control Panel
Yes

Ambient Temperature for Operation
Specified in product manual

External Supply Voltage Requirement for Digital I/O
Yes, at connection points X31.8 and X31.9

Control Panel Interface Connection Point
H1

Memory Card Slot Connection Point
X7

Serial Interface Connection Point
X2

After-Sales Support
Available from Indramat USA
