R911329849 (CSH01.1C-S3-EN2-NNN-NNN-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN2-NNN-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911329849 (CSH01.1C-S3-EN2-NNN-NNN-L2-S-NN-FW) module from Bosch Rexroth is engineered for industrial automation and control systems. It is equipped with an L2 safety option (safe torque off) and supports SERCOS III master communication. The unit operates on a 24 VDC supply with a power consumption of 7.5 W. It features an option 1 EnDat 2.1 encoder interface (6 W consumption), 11 digital inputs, 2 analog outputs, 1 analog input, and an RS232 serial port. Adjustable digital and analog outputs, along with specialized cycle time functions, enable precise control of velocity, current, and position. The device incorporates a relay contact with variable switching frequencies, supports a peak pulse width of 100 ms, and can handle an inrush current of up to 4 A.

Technical Specifications

Safety Option
L2 (safe torque off)

Communication Module
SERCOS 3

Power Source
24-volt DC

Power Consumption
7.5 watts

Option 1 Encoder
EnDat2.1, 6W

Digital Inputs
11

Analog Inputs
1

Serial Ports
RS232

Digital Outputs
4 (modifiable)

Analog Outputs
2 (modifiable)

Velocity Control Cycle Time
125-250 microseconds

Current Control Cycle Time
62.5-125 microseconds

Position Control Cycle Time
250-500 microseconds

Control Panel
1W (sold separately)

Relay Contact
1

Switching Frequency
2-16 Hz

Maximum Pulse Width
100 ms

Inrush Current
4 A
