R911329862 (CSH01.1C-SE-EN2-MEM-MA1-S2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth R911329862 (MPN: CSH01.1C-SE-EN2-MEM-MA1-S2-S-NN-FW) is a control section from the CSH01.1C series with dimensions of 103 mm × 241 mm × 49.5 mm. It features a standard control panel and supports two analog outputs via connector X8. The primary master communication interface is SERCOS, while the primary encoder interface at X4 accommodates EnDat 2.1, 1 Vpp, and TTL. Safe Motion functionality is implemented at connection point X41, compliant with SIL2/cat. 3 PL d. The device is rated IP20, intended for cabinet installation in environments with ambient temperatures between 0 °C and +40 °C.

Technical Specifications

Product Type
Control Section

Dimensions
103mm x 241mm x 49.5mm

Encoder Interfaces Support
EnDat 2.1, 1Vpp, TTL

Connection Points
H1, X4, X8, X41

Safety Feature
Safe Motion (SIL2/ cat. 3 PL d)

Temperature Range
0 to +40 degree Celsius

Protection
IP20

Hazard Precaution
Sensitive to moisture, fog, liquids

Seller
Indramat USA
