R911329872 (CSH01.1C-SE-ENS-EN2-MD2-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-ENS-EN2-MD2-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 41 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911329872 (CSH01.1C-SE-ENS-EN2-MD2-S2-S-NN-FW) is a Bosch Rexroth control section featuring advanced motion control capabilities within a compact housing measuring 103 mm x 49.5 mm x 241 mm. Designed with an IP20 protection rating, it safeguards against solid object ingress and is suitable for installation at heights ranging from 0 to 1000 meters above sea level. The module incorporates a SERCOS III master communication interface for high-speed data exchange, and offers two analog outputs. Encoder compatibility includes Indradyn, Hiperface, 1 Vpp, and TTL options. The control section provides dedicated connection points for a serial interface, control panel interface, memory card slot, and digital/analog I/O ports. It includes a standard-size control panel with a single-line display. The device is not intended for frequent mounting and dismounting, and correct firmware selection is required for proper operation.

Technical Specifications

Product Type
Control Section

Degree of Protection
IP20

Application Range
0 to 1000 meters above sea level

Communication Interface
SERCOS III

Control Panel Type
Standard with single-line display

Dimensions
103mm x 49.5mm x 241mm

Mounting
Single installation recommended

Firmware Requirement
Separate order (not included in package)

Package Contents
Control section device and user book

Packaging
Secure packaging to ensure damage-free delivery
