R911329889 (CSH01.3C-NN-EN2-MEM-CCD-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-NN-EN2-MEM-CCD-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911329889 (CSH01.3C-NN-EN2-MEM-CCD-L2-S-NN-FW) is a control section designed for integration in precise system configurations, supporting two analog outputs and a primary encoder with EnDat 2.1/1 Vpp/TTL interface. The unit requires continuous grounding, and erroneous parameter settings may cause unsafe mechanical operation. It features vertical axis protection to prevent uncontrolled motion after power loss and must be set to standstill before entry into the hazardous area. The MEM optional module provides encoder emulation for signal evaluation, requiring shielded wiring. The device conforms to IEC 61800-3 standards, operates in dry environments free of salt mist or condensation, supports two wires per terminal, accommodates a maximum pulse width of 100 ms, and has a typical inrush current of 4 A. Voltage adaptation is managed via the HAS05.1-003 converter. All attached components must be explicitly specified for compatibility.

Technical Specifications

Size
Smaller than Power Section

Optional Module
MEM featuring Encoder Emulation

Distribution Category
C3 in accordance with IEC 61800-3

Surface Condition
No Salt Mist or Condensation

Shipping
International

Maximum Pulse Width
100ms

Inrush Current Rating
Typical 4A

Number of Connections Supported
Two Conductors to a Single Terminal

Connection Method
TWIN Ferrules or Wires of Same Cross-Section

Terminal Blocks
Screw Terminal Blocks with Ferrules
