The Bosch Rexroth MPN R911329891 (CSH01.3C-NN-ENS-EN2-CCD-S2-S-NN-FW) is a control unit designed for integration with compatible machinery. The CSH01.3C control section provides encoder support for Indradyn, Hiperface, 1 Vpp, and TTL via the X8 interface. It features two analog outputs and includes a Safe Motion interface at X41. This device operates effectively at altitudes up to 1000 meters and within a temperature range of 0 to +40°C. It supports switchable pulse frequencies from 2 to 16 kHz. Master communication interfaces are not equipped. Proper installation is required by a certified technician and firmware must be sourced separately.

Technical Specifications

Product
Bosch Rexroth CSH01.3C Control Section

Maximum Installation Height
1000 meters above sea level

Motor Encoder Interfaces
Hiperface, 1Vpp, TTL

Temperature Range
0 to +40

Frequency Range
2 to 16 kHz

Extra Feature
Safe Motion feature

Configuration
Multiple input/output ports

Firmware Order
Separately from Indramat USA

Commissioning Requirement
Certified technician
