R911329895 (CSH01.3C-PB-EN2-EN2-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN2-EN2-CCD-S2-S-NN-FW Series Image

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 16 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911329895 (CSH01.3C-PB-EN2-EN2-CCD-S2-S-NN-FW) is a single-axis drive controller from the IndraDrive CSH series, suitable for use in machine tool applications, handling and mounting systems, and food packaging and processing equipment. This model features selectable switching frequencies of 2, 4, 8, 12, or 16 kHz. It is equipped with a Safe Motion Module for safety-related motion control functions, PROFIBUS master communication, and cross-communication capabilities. The controller provides two analog outputs and two encoder evaluation interfaces for 5V encoders, supporting EnDat 2.1, 1 Vpp, and TTL primary encoder options. A standard control panel with single-line display is used for device status indication, error diagnosis, and basic configuration procedures. Firmware usage is supported for operation adaptability.

Technical Specifications

Inrush Current
4A

Maximum Pulse Width
100ms

Switching Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, 16 kHz

Safe Motion Module
Yes

Communication Modules
PROFIBUS and Cross Communication

Encoder Evaluation Interfaces
2

Supply Voltage for Encoders
5V

Control Panel
Single-line display

Firmware
Allowed
