R911329897 (CSH01.3C-PB-EN2-MA1-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN2-MA1-CCD-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911329897 (CSH01.3C-PB-EN2-MA1-CCD-S2-S-NN-FW) is a control section designed for precise operation and monitoring of asynchronous and synchronous motors. It integrates a PROFIBUS interface via an optional module in compliance with DIN EN 50170, providing two analog outputs and EnDat 2.1/1 Vpp/TTL as the primary encoder option. The unit features a dedicated X41 port for Safe Motion modules and utilizes a standard control panel equipped with a single-line display and four keys for analog input adjustments. Digital I/O is configured in alignment with IEC 61131 standards, including an E-Stop function with factory settings. It supports multimedia card memory storage and provides a 1 ADC capacity for the Type 2 relay contact. The device must be installed within a control cabinet and operated according to specified safety guidelines.

Technical Specifications

Bus Cable Standard
DIN EN 50170

PROFIBUS optional module compatibility
No

Connected Point for Safe Motion Module
X41

Control Panel
Standard Single Line Display with Four Keys

Memory
Supports Two Variants of Multimedia Cards

Current Carrying Capacity of Type 2 Relay Contact
1ADC

Specifications of Digital I/O
IEC 61131

Combined Digital I/O with E-Stop Factory Setting
1

Mounting
Inside a Control Cabinet

Cleaning
No Connection to Electric Power When Cleaning

Shipping
Worldwide.
