R911329901 (CSH01.3C-PB-ENS-ENS-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-ENS-ENS-CCD-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MPN R911329901 (CSH01.3C-PB-ENS-ENS-CCD-S2-S-NN-FW) is a Rexroth IndraDrive CSH01.3C control section engineered for use with two types of 12V encoders, including interfaces compatible with IndraDyn S motors. It features a PROFIBUS master communication module and supports primary encoder options such as IndraDyn, Hiperface, 1 Vpp, and TTL. The unit incorporates a safety module for safe motion and delivers two analog outputs. Ethernet connectivity adheres to the IEEE 802.3 standard, supporting Cat-5e cables with lengths up to 100 meters. The control section is designed for standardized control panels using a one-line display; it does not permit hot plugging. Firmware is managed and identified separately by type plate labeling. Only qualified personnel should perform installation and integration of this unit and related modules.

Technical Specifications

Encoder Modules Supported
2

Cross-Communication Module
Yes

Ethernet Interfaces
2

Ethernet Compliance
IEEE 802.3

Maximum Cable Length
100 meters

Minimum Bend Radius (Flexible Installation)
48.75 mm

Minimum Bend Radius (Permanent Installation)
32.50 mm

Safety Module
Yes

Safe Motion Support
Yes

Control Panel Compatibility
Standard with single-line display

Firmware
Sold Separately

Installation
Qualified personnel only
