CSH01.3C-PB-ENS-MA1-CCD-S2-S-NN-FW Series Image

In Stock, Ships in 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911329903 (CSH01.3C-PB-ENS-MA1-CCD-S2-S-NN-FW) is an IndraDrive ADVANCED control section from the CSH series designed for single-axis applications. It is equipped with a standard control panel featuring a display and four operating keys, supporting adjustment of drive parameters and access to operational information. Interface connections utilize spring terminals and screw terminal blocks. The unit supports encoder connections such as Resolver (without data memory), Hall sensor box SHL01.1, and HSF encoder interface. An Analog I/O Extension is integrated, providing two differential analog input channels and two analog output channels, both with 12-bit resolution. Master communication is handled via PROFIBUS, with primary encoder options including Indradyn, Hiperface, 1 Vpp, and TTL signals.

Technical Specifications

product
Bosch Rexroth CSH Control Section

range
ADVANCED

control panel
standard

display
single-line

operating keys
four

connection points
spring terminals and screw terminal blocks

use
industrial areas

encoder interface
Resolver and HSF

encoder supply voltage
DC 8V or AC 18.2V peak-peak
