R911330346 (CSH01.1C-CO-NNN-NNN-NNN-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-CO-NNN-NNN-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330346 (CSH01.1C-CO-NNN-NNN-NNN-L2-S-NN-FW) is a control section module for Bosch Rexroth IndraDrive systems, featuring two analog outputs and supporting master communication via CANopen/DeviceNet protocols. This unit includes a standard control panel for monitoring system parameters, warnings, and errors, and allows execution of basic commands. The safety functionality includes a safe torque off feature, which disconnects drive output power to facilitate controlled motor stopping. The module accommodates up to three optional extensions, is not equipped with a primary encoder, and requires separate firmware installation. The device should only be handled using ESD precautions and by qualified personnel, with installation limited to a maximum of 20 cycles.

Technical Specifications

Use
Control Device for IndraDrive Systems

Control Panel
Parameters, Errors and Warnings Monitor

Safety Feature
Safe Torque Off

Optional Modules Space
Three

Optional Modules Included
None

FirmWare
Has to be ordered separately

Mounting Requirement
On a Power Section

Mount/Unmount Limit
20 Times

Assembly
Only by Trained Personnel

Risk
Electrostatic Charges

Handling Precaution
ESD Precautions

Packaging
Conductive Packaging

Communication
CANopen/DeviceNet
