R911330538 (CSH01.1C-NN-ENS-EN2-MD2-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-ENS-EN2-MD2-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330538 (CSH01.1C-NN-ENS-EN2-MD2-S2-S-NN-FW) is a control section designed for integration with Rexroth drive controllers in automated drive systems. Engineered for natural convection cooling, this module supports multiple encoder interfaces at connection point X4, including IndraDyn, Hiperface, 1Vpp, and TTL, while X8 provides EnDat 2.1, 1Vpp, and TTL compatibility. Two analog outputs are available. Digital I/O extension is provided at X10 for peripheral integration. Safety features such as Safe Motion (SIL2/cat 2 PL d) are available at X41. This MPN must be configured by qualified personnel.

Technical Specifications

Product
Bosch Rexroth Control Section

Design Feature
Natural Cooling

Configuration
Configurable before operation

Installation
Requires well-trained technician/engineer

Function
Essential part of drive controller system

Master Communication Interface
Not equipped

Encoder Interfaces at X4
Supports IndraDyn, Hiperface, 1Vpp, TTL

Encoder Interfaces at X8
Supports EnDat 2.1, 1Vpp, TTL

Digital I/O Extension
Equipped at connection point X10

Safety Features
Safe Motion (SIL2/cat 2 PL d) at X41

Shipping
Worldwide shipping provided by Indramat USA

Compatibility
Should be used with Rexroth approved devices
