R911330539 (CSH01.3C-PB-ENS-EN1-CCD-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-ENS-EN1-CCD-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330539 (CSH01.3C-PB-ENS-EN1-CCD-L2-S-NN-FW) is a Bosch Rexroth control section equipped with integrated encoder interfaces supporting IndraDyn, Hiperface, 1 Vpp, and TTL standards for precise encoder signal evaluation. Data transfer is supported via a preloaded multimedia card. The unit provides two analog voltage outputs and optional use as digital input, conforming to IEC 61131 standards, with 8-fold oversampling, 1.4kHz input bandwidth, and 1.23mV per increment resolution. The device features PROFIBUS master communication, dual-mode control cycle times based on firmware, and uses green and yellow LEDs for network and data status indication. The emergency stop function is hardware accessible, and RKG4200 cables provide direct connection to the encoder. A cooling period of 15 minutes is required after continuous operation.

Technical Specifications

Encoder Type
IndraDyn / Hiperface / 1 Vpp / TTL

Memory Requirement
Multimedia Card

Analog Voltage Inputs
2

Voltage Rating
+/-10V

Resistance
160 kiloOhms

Control Cycle Times
Varies with firmware

Emergency Stop Switch
Required

Cooling Time
Minimum 15 minutes

Analog Inputs Compliance
IEC 61131

Backup Support Period
One Year

Interface
Serial Interface

LED Indicators
Green and Yellow

Encoder Output Current Rating
500mA

Encoder Voltage Rating
11.6V

Encoder Supply Voltage Rating
12V

Inrush Current
4A

Maximum Pulse Width
100ms

Delivery Method
Trustworthy Logistics Agents
