R911330610 (CSH01.1C-PB-NNN-NNN-MA1-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-NNN-NNN-MA1-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330610 (CSH01.1C-PB-NNN-NNN-MA1-NN-S-NN-FW) is an industrial drive controller developed for precision automation control in servo systems. This unit features a modular structure for integration within larger automation frameworks and supports 7 to 11 digital inputs and four digital outputs for real-time data handling. It is equipped with two analog outputs and interfaces with master communication via PROFIBUS, with no primary encoder option installed. Operating specifications include a consumption of 7.5 watts, average inrush current of 4 amperes, and typical leakage current of 3.5 milliamperes, with required grounding. Control cycle times are 62.5 microseconds for current and 125 microseconds for velocity, with five selectable switching frequencies from 2 to 16 kilohertz.

Technical Specifications

Product Type
Industrial Drive Controller

Design Standard
American and European Quality Standards

Design type
Modular

Expected Lifespan
More than 5 years under ideal operating conditions

Power Consumption
7.5 watts

Inrush Current
4 amperes

Leakage Current
3.5 milliamperes

Digital Input Interfaces
7 to 11

Digital Output Interfaces
4

Velocity Control Time
125 microseconds

Current Control time
62.5 microseconds

Switching Frequencies
2, 4, 8, 12, and 16 kilohertz.
