The R911330658 (CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW) is a Bosch Rexroth advanced control section engineered for vertical mounting. It accommodates a memory card via the X7 connector and features two 9-pin connectors (X31 and X32) for digital I/O. The IA1 input is designed for low impedance signal sources, and HSF/RSF encoders are connected through the X4 interface. The unit provides two analog voltage outputs and two analog voltage inputs, with the latter capable of serving as digital inputs. It supports MultiEthernet as the master communication protocol and integrates with machine tools and handling or mounting systems through compatible power sections and drive controllers. The control section includes a standard control panel and RS-232 serial interface. Proper grounding is required when managing exposed conductive parts. Firmware is supplied separately.

Technical Specifications

Product Type
Advanced Control Section

Design Code
1

Memory Card Compatibility
Yes (X7 Connector)

Digital Outputs and Inputs Connectors
X31 and X32 (9 pins each)

IA1 Input Signal Source Impedance Requirement
Low

Configuration Possibility
First Two Digital Inputs as Probes

Voltage Rating
24V

Current Rating
3mA

Encoder
HSF/RSF (15-pin) on X4 Connector

Supply Voltage Encoder
8VDC or 12VAC Peak-to-Peak

Analog Voltage Inputs
2

Voltage Rating Analog Voltage Inputs
+/-10V

Resistance Analog Voltage Inputs
10 Ohms

Firmware
Bought Separately

Storage and Transport Requirement
Conductive Packaging

Interface
RS 232 Serial

Control Panel
Standard

Packaging
Military Grade
