R911330812 (CSH01.3C-PB-EN1-NNN-CCD-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN1-NNN-CCD-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330812 (CSH01.3C-PB-EN1-NNN-CCD-NN-S-NN-FW) is a control section from Bosch Rexroth, designed for industrial electric motor management in environments such as assembly and food processing systems. It uses spring terminals and screw terminal blocks to provide secure connections that are resilient to mechanical stress and vibrations. Classified as a Category C3 device under IEC 61800-3, it can generate high-frequency interference and may require measures for radio-interference suppression. The module features two analog outputs, incorporates a standard control panel for system interaction, and allows setup and monitoring of positioning and error memory functions. Integrated interfaces include a Resolver and HSF encoder evaluation supporting DC 8V or AC 18.2V peak-peak power, with master communication supported via PROFIBUS and cross-communication according to IEEE 802.3. Firmware is required and must be installed separately.

Technical Specifications

Product Type
CSH control sections

Product Category
C3 (IEC 61800‑3)

Electrical Connectors
Spring terminals, Screw terminal blocks

Radiation Interference
Requires additional radio interference suppression

Firmware Support
Yes (must be ordered separately)

Control Panel
Standard

Encoder Interface
Resolver and HSF

Encoder Supply Voltage
DC 8V or AC 18.2V peak-peak

Communication Module
PROFIBUS, IEEE 802.3 compatibility

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.3C-PB-EN1-NNN-CCD-NN-S-NN-FW.

Exchange

Want to sell your CSH01.3C-PB-EN1-NNN-CCD-NN-S-NN-FW?
