R911330813 (CSH01.3C-PB-EN2-MA1-CCD-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN2-MA1-CCD-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330813 (CSH01.3C-PB-EN2-MA1-CCD-NN-S-NN-FW) is a Bosch Rexroth control section designed for use with compatible drive controllers. It integrates a PROFIBUS interface with LED status indication and supports communication using EIA-RS485 standards. The unit provides two analog outputs, a configuration slot, one relay contact, and optional analog I/O expansion. For position feedback, it includes EnDat 2.1, 1 Vpp, and TTL encoder compatibility. Correct function requires vertical installation, proper grounding, a functional emergency stop switch, and at least 15 minutes cooldown after operation. A termination resistor must be used on the communication interface to prevent overload.

Technical Specifications

Functionality
Cannot function independently

Feature
LED on PROFIBUS interface

Mounting and Installation
Only in vertical orientation

Usage Restrictions
Cannot be used for unauthorized applications

Control Panel Battery type
Specified type only

Handling
Use suitable protective equipment

Configuration Slot
One

Safety technology
Not present

Software
Firmware has to be ordered separately

Relay Contact Count
One

Extension Option
Analog I/O extension optional module

Data Transmission
EIA-RS485 standard via PROFIBUS interface

Terminating Resistor
Connectable

Shipping
Available globally
