R911330898 (CSH01.3C-ET-ENS-MA1-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-ET-ENS-MA1-CCD-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911330898 (CSH01.3C-ET-ENS-MA1-CCD-S2-S-NN-FW) is a single-axis control section designed for use within the IndraDrive system. It features master communication capability via a Multi-Ethernet module compatible with field bus systems such as ProfiNet, SERCOS III, and EtherCAT. Integrated status LEDs indicate network and data transmission conditions. The unit provides two analog outputs through its Analog I/O Extension, and accommodates primary encoder interfaces including Indradyn, Hiperface, 1 Vpp, and TTL. It supports encoder evaluation at 12V and operates at selectable switching frequencies of 2 kHz, 4 kHz, 8 kHz, 12 kHz, or 16 kHz. Cross-communication conforms to IEEE 802.3 standards. Firmware is required and must be ordered separately.

Technical Specifications

Product Line
Bosch Rexroth IndraDrive

Product Type
Single-axis Control Section

Module Type
Multi-Ethernet

Analog I/O Extension
Yes

Integrated LEDs
Yes

Analog Input Channels
2

Analog Output Channels
2

Analog Channel Resolution
12-bit

Standards Compliance
IEEE 802.3

Encoder Evaluation Interface
Standard

Encoder Supply Voltage
12V

Communication
Cross Communication Interface

Switching Frequencies
2 kHz, 4kHz, 8kHz, 12 kHz, 16kHz

Firmware
Supported but ordered separately

Field Bus Systems Compatibility
ProfiNet, SERCOS III, EtherCAT.
