R911331006 (CSH01.1C-ET-EN1-EN2-NNN-L2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911331006 (CSH01.1C-ET-EN1-EN2-NNN-L2-S-NN-FW) is a Rexroth IndraDrive control section designed for integration within HCS and HMS drive controller systems. It supports error monitoring, analog output adjustment, and modification of fieldbus data transmission, with current control cycle time of 62.5 ms and velocity control cycle time of 125 ms. The unit features two analog outputs, MultiEthernet master communication, and a primary encoder interface supporting HSF/RSF types. It is programmable, includes an active safety system, and supports communication over the PROFInet IO master. Fiber optic connectivity to the SERCOS interface is provided. Typical inrush current is 4 A, and power consumption is 7.5 kW. Operation must follow manufacturer guidelines to ensure correct function.

Technical Specifications

Rexroth IndraDrive Framework Component
Yes

Use
Industrial

Use with HCS and HMS Drive Controllers
Yes

Control Panel
Conventional

Error Checks
Yes

Analog Output Modifications
Yes

Fieldbus Data Transmission Change
Yes

Cycle Time for Current Control
62.5 ms

Cycle Duration for Velocity Control
125 ms

Regular Inrush Current
4 Amperes

Power Consumption
7.5 kW

Pulse Width
100 ms

Safety Features
Included

Connection Interface
SERCOS via fiber optics

Programmable
Yes

Active Safety System
Yes

Communication
Via PROFInet IO master

Supports Supplemental Modules
Three (3)

Power Usage
6W per encoder

Ambient Conditions
As per product documentation.
