The Bosch Rexroth MPN R911331009 (CSH01.1C-S3-EN1-ENS-NNN-S2-S-NN-FW) is a CSH01.1 control section engineered for electric drive and motion control applications in industrial environments. This unit incorporates a HSF/RSF encoder in the X4 slot with a 6 W power requirement, programmable digital outputs, two analog outputs, and support for analog inputs. It features SERCOS III as the primary communication protocol and includes an IndraDyn/hiperface encoder at X8, also drawing 6 W. Safety is addressed through an S2 (safe motion) function and a polarity-reversal protection diode. The unit supports timing cycles for position, current, and velocity control, accommodates a 4 A inrush current, and is suitable for installation within specified temperature and humidity conditions.

Technical Specifications

Product Type
Electric drive and motion control technology

Encoder
HSF/RSF

Power Requirement for Encoder
6W

Programmable Digital Outputs
4

Analog Inputs
1

Analog Outputs
2

Inrush Current
4A

Appropriate Usage Temperature and Humidity
Specific Range

Required Installation
By Certified Technician

Safety Regulation
Standard Installation and Safety Rules

Velocity Cycle Time
Between 125 and 250 microseconds

Current Cycle Time
Between 62.5 and 125 microseconds

Position Cycle Time
Between 250 and 500 microseconds

Protection Measure
Diode

Relay Contact
Single

Switching Frequency
Between 2 to 16 Hz

Encoder in X8 Slot
IndraDyn/hiperface

Power Requirement for X8 Slot
6W

Safety Option
S2 (safe motion)

Firmware
Needs to be purchased separately

Control Panel
Conventional

Digital Inputs
11

Communication Module
SERCOS 3

Minimum Cycle Time
250 milliseconds.
