R911331252 (CSH01.3C-PB-ENS-MA1-CCD-NN-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911331252 (CSH01.3C-PB-ENS-MA1-CCD-NN-S-NN-FW) is a Bosch Rexroth CSH digital control unit designed for single-axis motion control applications. It is equipped with a single-line display and a four-button keypad for direct access to diagnostics, command execution, and parameter adjustment at the drive controller. This unit facilitates drive address configuration, SERCOS transmission power control, position reference setting, error memory access, and initiation of load default procedures. It provides two analog outputs and is compatible with IndraDyn, Hiperface, 1 Vpp, and TTL encoders. The control unit includes Profibus for master communication, enabling high-speed data exchange and flexible integration within industrial automation networks.

Technical Specifications

ProductType
Digital Control Unit

ProductLine
Bosch CSH

ApplicationType
Single Axis

Availability
Configurable

CommunicationSupport
Profibus Master Communication

PhysicalLayerOptions
RS-485, RS-232

BuiltInDiagnostics
Yes

DataTransmissionSpeed
9.6 kbit/s to 12 Mbit/s

NetworkTopology
Point-to-Point, Multidrop, Bus Systems
