R911331447 (CSH01.1C-CO-EN2-NNN-NNN-S2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth control section R911331447 (CSH01.1C-CO-EN2-NNN-NNN-S2-S-NN-FW) is designed for IndraDrive controllers, providing support for various encoder options including EnDat 2.1, 1 Vpp, and TTL. It is equipped with two analog outputs and enables master communication via CANopen or DeviceNet. The module features safe torque off functionality and an integrated RS-232 interface for drive commissioning. Dimensions are 241 mm (height), 49.5 mm (width), and 103 mm (depth). The front panel houses a memory card slot, interfaces for a serial port, and analog and digital I/O. Assembly, disassembly, and handling must be performed by qualified personnel, not exceeding 20 cycles, and conductive packaging is required to prevent electrostatic damage.

Technical Specifications

IndraDrive Controller Component
Control Section

Supports Encoder
EnDat 2.1 interface

Safety Option
Safe Motion

Firmware
Order Separately

Assembly
Plugs into the power section of the drive

Electrostatic Discharge Protection
Yes, through grounding

Storage and Transport
Inside conductive packaging

Maximum Mounting/Dismounting Limit
20 times.
