R911331570 (CSH01.1C-SE-ENS-EN1-MD2-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-ENS-EN1-MD2-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911331570 (CSH01.1C-SE-ENS-EN1-MD2-L2-S-NN-FW) is a control section component for Bosch IndraDrive controllers, suitable for integration in industrial automation systems. Identification is provided by a type plate on the unit, and firmware selection is dependent on the specific application requirements. The unit features an RS-232 interface for serial connectivity, supports multiple control cycle times and switching frequencies, and includes two analog outputs. It is equipped with an I/O extension module for SSI encoder interfaces and offers a safety module supporting the safe torque off function. Master communication is implemented via a SERCOS interface, enabling high-speed serial data exchange in a master/slave arrangement. Configuration can be performed via a standard control panel, and the unit utilizes convection cooling. Primary encoder compatibility includes Indradyn, Hiperface, 1 Vpp, and TTL.

Technical Specifications

Product type
Control section for IndraDrive controllers

Applicable Industry
Industrial

Identification Method
Type plates

Firmware
To be ordered separately

Mounting Method
Mounts onto a power section

Interface
RS-232

Current Control Cycle times (microseconds)
62.5 and 125

Velocity Control Cycle times (microseconds)
125 and 250

Position Control Cycle times (microseconds)
250 and 500

Minimum SERCOS cycle time(microseconds)
250

Switching Frequencies (kilohertz)
2, 4, 8, 12, 16

Extension Module
Digital I/O

Module Features
connection to SSI encoder interfaces

Safety Module
Support safe torque off

Master Communication Interface
SERCOS

Topology
Line or ring

Control panel type
Standard; does not support hot plug

Cooling method
Convection cooling
