The R911331572 (CSH01.3C-PB-EN1-ENS-CCD-S2-S-NN-FW) is a single-axis control section from the Bosch Rexroth CSH series, intended for integration with IndraDrive drive controllers to manage electric motor functions. It incorporates a PROFIBUS interface for master communication, facilitating real-time data exchange with system components. The unit supports permitted switching frequencies of 2 kHz, 4 kHz, 8 kHz, 12 kHz, and 16 kHz and is equipped with a cross-communication module compliant with IEEE 802.3 for Ethernet connectivity. Diagnostic LEDs provide status indication. Safety features include safe maximum speed, safely limited position, safe direction, and safe homing. Encoder evaluation supports sin-cos and 5V-TTL square-wave encoders (12V supply), and two analog outputs are provided. The control section includes a standard control panel for configuration.

Technical Specifications

Product Type
Control Section

Communication Interface
PROFIBUS

Cross Communication Module Standard
IEEE 802.3

Permitted Switching Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, 16 kHz

Safety Technology
Safety Technology I/O

Encoder Supply Voltage
12V

Control Panel
Standard Control Panel
