R911331576 (CSH01.1C-SE-EN1-NNN-MA1-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN1-NNN-MA1-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch R911331576 (CSH01.1C-SE-EN1-NNN-MA1-S2-S-NN-FW) is a control unit from the IndraDrive series engineered for advanced single-axis control. It is equipped with SERCOS interface for master communication and an HSF/RSF encoder module, suitable for both digital servo feedback and resolver applications. The unit provides two analog outputs and includes one configuration slot for safety technology, featuring a factory-installed safety module that enables safe motion functions and requires an encoder. An optional I/O extension module can be used to increase analog input/output capacity. Installation or removal must be conducted by qualified personnel.

Technical Specifications

Product Line
IndraDrive

Control Unit Type
Advanced

Function
Single-axis control

Configurability
Yes

Control Panel Compatibility
Standard only

Safety Technology Configuration Slots
1

Factory-installed Safety Module
Yes

Safe Motion Feature
Yes

Encoder Requirement for Safe Motion
Yes

Encoder Voltage Supply
8 Volts DC or 18.2 Volts AC peak-peak

Power Section Compatibility
Yes

Control Unit and Power Section Assembly
Only by trained personnel.
