R911331931 (CSH01.3C-ET-EN1-EN2-CCD-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-ET-EN1-EN2-CCD-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911331931 (CSH01.3C-ET-EN1-EN2-CCD-NN-S-NN-FW) is a control section in the CSH series by Bosch Rexroth, featuring dimensions of 103 mm x 49.5 mm x 241 mm. It provides two analog outputs, master communication via MultiEthernet, and supports HSF/RSF as the primary encoder option. The unit is equipped with digital and analog input/output ports, a memory card slot (X7), control panel interface (H1), and a serial interface (X2) for data transfer. The supported operating temperature range is 0 to +40°C, with humidity up to 90%, and the device is rated at IP20, requiring protection against condensation. External voltage supply is needed for digital I/Os at X31.8 and X31.9. Firmware must be ordered separately. This unit is not intended for frequent mounting and dismounting, and appropriate protection, such as use of a protective diode, is recommended to prevent incorrect connections.

Technical Specifications

Type
Control Section

Input-Output Points
Multiple

Memory Card Slot
Available at X7

Control Panel Interface
Available at H1

Dimensions
103mm x 49.5mm x 241mm

Operating Temperature Range
0 to +40 degree Celsius

Humidity Requirement
below 90%

Protection Class
IP20

Serial Interface
Available at X2

Ethernet interface
Multi-Ethernet

Mounting and Dismounting
Not Frequent

External Supply Voltage Requirement at Connection Points X31.8 and X31.9
Yes
