R911331933 (CSH01.3C-ET-ENS-MEM-CCD-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-ET-ENS-MEM-CCD-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911331933 (CSH01.3C-ET-ENS-MEM-CCD-L2-S-NN-FW) is a Bosch Rexroth IndraDrive CSH01.3C control section designed for electric motor control and monitoring within drive systems. It supports various encoder types, including sin-cos encoders with EnDat 2.1 or Hiperface, as well as 5V-TTL square-wave encoders with a reference track. The unit provides two analog outputs and primary encoder options such as Indradyn, Hiperface, 1 Vpp, or TTL. Integrated MultiEthernet master communication enables connection to multiple Ethernet-based fieldbus networks. Additional features include encoder emulation for generating absolute and incremental signals, LEDs for diagnostic status indication, and a Safe Torque Off (STO) function.

Technical Specifications

Product Type
ADVANCED CSH Control Section

Component of Drive Controllers
Yes

Interfaces
Encoder Emulation, Multi-Ethernet

Encoder Evaluation Interface Standard Supply Voltage
12V

Inrush Current
4A

Maximum Pulse Width
100ms

Ethernet Field Bus Systems
SERCOS III, EtherCAT, ProfiNet

LEDs Indicators
Yes

Safety Feature
Safe Torque Off (STO) Module

Firmware Compatible
Yes.
