R911332416 (CSH01.3C-ET-EN1-ENS-CCD-S2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911332416 (CSH01.3C-ET-EN1-ENS-CCD-S2-S-NN-FW) is a Bosch Rexroth CSH01.3C-series control unit designed for advanced motion control applications. This module features MultiEthernet for master communication and supports HSF/RSF encoder interfaces at X4. It includes two analog outputs, various serial and control interfaces at X2, X24, X25, and H1, and a memory card slot at X7. The unit requires external supply voltage for digital I/Os via X31.8 and X31.9. Dimensions are 103mm x 49.5mm x 241mm; operation is specified from 0°C to +40°C with relative humidity below 90%. Protection from incorrect polarity and electromagnetic interference is necessary.

Technical Specifications

Product Type
Control Unit

Product Family
CSH01

Operating Temperature
0 to +40 degrees Celsius

Humidity
Below 90%

Dimensions
103mm x 49.5mm x 241mm

Supply Voltage Connection Points
X31.8 and X31.9

Protection
Protective Diode in Power Supply

Radiation Protection
Safe Distance From Electromagnetic Radiation.
