R911332419 (CSH01.3C-PB-EN2-EN2-CCD-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN2-EN2-CCD-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The CSH control section MPN R911332419 (CSH01.3C-PB-EN2-EN2-CCD-NN-S-NN-FW) is designed for integration in IndraDrive systems for the monitoring and control of electric motors in industrial automation. It provides two D-sub, 15-pole encoder evaluation interfaces compatible with sin-cos and 5V-TTL encoders, supporting both linear and rotary motion control applications. Key features include 2 analog outputs, support for the PROFIBUS master communication protocol, and a primary encoder option of EnDat 2.1/1 Vpp/TTL. It operates with a 4A inrush current, a maximum pulse width of 100ms, and incorporates a cross communication module compliant with IEEE 802.3. Classified as Category C3 and engineered for resistance to electromagnetic interference, this control section is paired with a standard control panel and supports separate firmware installation.

Technical Specifications

Product
Bosch Rexroth CSH Control Section

Interface Type
D-sub-type 15 poles

Encoder Support
Sin-cos encoder, 5V-TTL square-wave Encoder

Supply Voltage
5V

Typical Inrush Current
4A

Maximum Pulse Width
100ms

Communication Network
PROFIBUS

EMI Resistance
Yes

Additional Module
Cross Communication Module IEEE 802.3

Applicable Standards
IEC 61800‑3 Category C3

Control Panel
Standard

Firmware
Order Separately
