R911332572 (CSH01.1C-S3-EN2-EN1-NNN-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN2-EN1-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911332572 (CSH01.1C-S3-EN2-EN1-NNN-S2-S-NN-FW) is an industrial motion control module designed for use in automation systems. It features S2 safe motion safety integrated into the drive controller. The unit supports SERCOS III master communication and has two analog outputs, four digital outputs, and eleven digital inputs. Primary encoder support includes EnDat 2.1, 1 Vpp, and TTL. It includes an encoder emulator available through the X10 interface. Minimum cycle time for SERCOS communication is 250 microseconds. The device measures 103 mm x 49.5 mm x 241 mm (WxDxH). Installation and operation must be performed by qualified personnel, as improper handling can result in equipment damage or safety hazards.

Technical Specifications

Safety Control
S2 safe motion safety

Control Panel
User-friendly

Encoder
EnDat2.1

SERCOS Minimum Cycle Time
250 microseconds

Analog Outputs
2

Digital Outputs
4

Digital Inputs
11

Inrush Current
4 amps

Power Consumption
7.5 watts

Communication Module
SERCOS 3

Communication Module Power Need
1 W

Additional Encoder
HSF/RSF

Additional Encoder Power Need
6 W

Width
103mm

Depth
49.5mm

Height
241mm

Application
Industrial Use

Interface
Single Serial Interface

Installation
By Certified Technician

Encoder Emulator Power Need
2 W
