R911332941 (CSH01.1C-PB-EN1-EN2-NNN-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-EN2-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911332941 (CSH01.1C-PB-EN1-EN2-NNN-S2-S-NN-FW) is a control section designed for use in drive systems. It supports dual analog outputs and is configured for PROFIBUS master communication. Encoder compatibility includes HSF and RSF interfaces, with support for multi-encoder connections using X4.1 and X4.2 connectors (EnDat 2.1, 1Vpp, and TTL). The unit is convection-cooled and suitable for operation at temperatures from 0 to +40°C and installation heights up to 1000 meters above sea level. Its control panel accommodates four keys and optional PROFIBUS modules. Proper configuration is necessary prior to operation; additional forced cooling is permitted if required.

Technical Specifications

Product
Bosch Rexroth Control Section

Functionality
Extended Scope, High-resolution Control

Current Consumption
Minimal

Connection Points
X4.1 and X4.2

Supported Encoder Systems
HSF, RSF, EnDat 2.1, 1Vpp, TTL

Cooling Mechanism
Natural Convection

Dimensions
103mm x 241mm x 49.5mm

Operating Temperature
0 to +40 degree Celsius

Moisture Content
Less than 90%

Maximum Installation Height
1000 MSL

Serial Ports
Available

Control Panel
4 Keys

Configuration
Prior to Operation

Cooling Requirements
Fan or Blower as Needed

Optional Module
PROFIBUS interface

Type Code Details
In Product Manual

Shipping
Worldwide, Damage-Free Delivery.
