R911332942 (CSH01.1C-PB-EN2-EN2-MEM-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN2-MEM-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911332942 (CSH01.1C-PB-EN2-EN2-MEM-S2-S-NN-FW) is a Bosch Rexroth control section equipped with S2 safety configuration. It features model width modulation from 2 to 16 kHz and dimensions of 103 mm × 241 mm × 49.5 mm. The device supports SERCOS cycle periods of 1000 µs, with current control response times of 62.5–125 µs and position control response times of 250–500 µs. Interface options include a single analog input, two analog outputs, 11 digital inputs, one RS232 serial port, and a PROFIBUS master communication module. Encoder support comprises an encoder emulator and dual encoder options with EnDat 2.1, 1 Vpp, and TTL compatibility. Firmware is supported via memory card adapter, and installation is recommended below 1000 m altitude.

Technical Specifications

Product Type
Control Section

Safety Feature
S2 (Safe Motion)

Physical Dimensions
103mm Width, 241mm Height, 49.5mm Depth

SERCOS Cycle Period
1000 Microseconds

Width Modulation
2 to 16 kHz Adjustable

Encoders
EnDat2.1 Encoder Option 1 and 2

Current Control Time
62.5-125 Microseconds

Position Control Time
250-500 Microseconds

Included Features
Single Analog Input, RS232 Serial Port

Digital Inputs
11 (2 as Touch Probes)

Inrush Current
4 Amp

Communication Module
PROFIBUS Master

Additional Feature
Encoder Emulator

Installation Height Recommendation
Below 1000 meters
