R911333192 (CSH01.1C-PB-ENS-EN1-NNN-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-EN1-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Indramat MPN R911333192 (CSH01.1C-PB-ENS-EN1-NNN-S2-S-NN-FW) is a motion control module suitable for installation at altitudes up to 1000 meters and an operational temperature range of 0 to 40 degrees Celsius. It supports a humidity range from 0 to 95% and must be protected from liquids and acids. Digital and analog I/O connections are provided at X31 and X32, while H1 interfaces with the control panel and X2 provides a serial interface. The module is equipped with 2 analog outputs and supports master communication via PROFIBUS. Encoder compatibility includes Indradyn, Hiperface, 1 Vpp, and TTL options. A single-line LED display control panel is present for error code indication.

Technical Specifications

Communication
PROFIBUS

Installation Height
Up to 1000 meters above sea level

Operating Temperature
0 to +40 degree Celsius

Safety Feature
Safe Motion (SIL2 / cat 3. PL d)

Relative Humidity
0 to 95%

Control Panel Interface
Terminal H1

Serial Interface
X2

Wire Size for Serial Interface
0.25 - 0.5 mm-square stranded wire

Connection Points
X31 and X32 for digital and analog inputs/outputs

Recommended Wire Size
0.75 - 1.5 mm square

Control Panel
Standard, with single-line LED display

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-PB-ENS-EN1-NNN-S2-S-NN-FW.

Exchange

Want to sell your CSH01.1C-PB-ENS-EN1-NNN-S2-S-NN-FW?
