R911333235 (CSH01.3C-PB-EN2-EN1-CCD-S2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 21 Seconds

The R911333235 (CSH01.3C-PB-EN2-EN1-CCD-S2-S-NN-FW) is a single-axis control section from the Bosch Rexroth CSH series designed for integration into the IndraDrive platform. This model supports flexible connectivity with two analog outputs and PROFIBUS as the master communication interface. It accommodates various encoder types via encoder evaluation, including EnDat 2.1, 1 Vpp, and TTL as its primary encoder options, and features Resolver and HSF interfaces with 15 poles each. The control section provides reliable performance under typical industrial conditions, with a maximum pulse width of 100 ms and a typical inrush current of 4 A. Separate firmware is required for operation. Plug-in cycles are limited to 20.

Technical Specifications

Design
3

Axis-Count
Single

Materials
Spring Terminals and Screw Terminal Blocks

Inrush Current
4A

Maximum Pulse Width
100ms

Firmware Compatibility
Yes, firmware must be ordered separately

Installation
Not to exceed 20 times
