R911333259 (CSH01.1C-ET-NNN-NNN-NNN-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-ET-NNN-NNN-NNN-NN-S-NN-FW Series Image

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911333259 (CSH01.1C-ET-NNN-NNN-NNN-NN-S-NN-FW) is a Bosch Rexroth CSH series control section featuring support for multiple encoder interfaces and MultiEthernet master communication. It integrates digital and analog inputs/outputs, with two analog outputs available, and can be configured via a PC using IndraWorks engineering software. The unit includes four front panel slots—three supporting optional modules and one for a dedicated safety module—accommodating various application requirements. It operates with a 24 VDC input and has a power consumption of 7.5 W. The control section is designed for single-axis positioning applications and utilizes a standard control panel for monitoring and parameter adjustment.

Technical Specifications

Control Interfaces
Encoder, Control Communication

Inputs/Outputs
Digital and Analog

PC Interface
IndraWorks Engineering Tool

Optional Module Slots
4 (3 User Configurable, 1 Safety Module)

Primary Use
Motor Control

Configurability
Yes

Control Panel Compatibility
Standard Only

Display Function
Operational Parameters Monitoring

Keypad Function
Limited Functionality

Power Supply Input
24 Volts DC

Power Consumption
7.5 Watts

Master Communication
Multi-Ethernet
