R911334050 (CSH01.1C-NN-EN2-ENS-MD2-S2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911334050 (CSH01.1C-NN-EN2-ENS-MD2-S2-S-NN-FW) is a control section from the IndraDrive series, designed for direct integration into the drive controller's power section. It supports selectable switching frequencies of 2 kHz, 4 kHz, 8 kHz, 12 kHz, and 16 kHz for precise speed and position control. The module offers two analog outputs, an ENS plug-in for encoder evaluation, and supports EnDat 2.1, 1 Vpp, and TTL encoder feedback options. External communication is facilitated via CANopen, and the control section operates without master communication capability.

Technical Specifications

Function
Control section for industrial drive controllers

Operational Switching Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, 16 kHz

Input Quantity
Single

Response Time
Short cycle times for rapid response

Additional Modules Compatibility
Yes

External Communication
CANopen
