R911334338 (CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

R911334338 (CSH01.1C-CO-EN2-NNN-NNN-L2-S-NN-FW) is a control section of the Rexroth IndraDrive CSH01 series, engineered for HCS, HMS, and HMD drive systems such as HCS02 and HCS03. It features safety technology, supports CANopen and DeviceNet communication via a 5-pin connector, and integrates two analog outputs. Encoder compatibility includes EnDat 2.1, 1Vpp, and 5 V TTL. The unit provides a safe torque off function, a standard operating panel for status, warning, and error diagnostics, and operates at 7.5 W with a 4 A maximum inrush current. It is designed for indoor environments, IP 20 protection, 3K3 climatic category, operating from -25°C to 70°C, and installation altitudes up to 1000 meters.

Technical Specifications

Component Type
Control Section

Use
Drive Controls Operation

Compatible With
HCS02,HCS03,HMS Drive Controllers

Safety Technology
Optional

Control Communications
DeviceNet,CANopen

Connector
Open-style 5-pin

Power Consumption
7.5 Watts

Inrush Current
4 Amperes

Encoder Interface
EnDat 2.1, 1Vpp, 5 V TTL

Operating Panel
Standard

Max Pulse Width
100 ms

Permissible Transport Temp
-25°C to 70°C

Recommended Storage Temp
-25°C to 55°C

Mounting
Control Cabinet

Operating Temp Range
0°C to 40°C

Installation Altitude
Below 1000m

Protection Class
IP 20

Climatic Category
3K3, IEC 721 Standards.
