R911334407 (CSH01.1C-PB-ENS-EN2-MD2-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-EN2-MD2-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MPN R911334407 (CSH01.1C-PB-ENS-EN2-MD2-L2-S-NN-FW) is a modular control unit designed for single-axis positioning applications. It integrates four module slots: one for a safety module with safe torque off, and three for functional modules, including a digital I/O extension in slot three providing 16 additional inputs and outputs. Slot one supports encoder modules compatible with IndraDyn, while slot two is assigned to EnDat 2.1 encoder support. The unit features two analog outputs, utilizes PROFIBUS as the master communication protocol, and supports primary encoders such as IndraDyn, Hiperface, 1 Vpp, and TTL. A D-sub 9-pin female interface and standard control panel configuration are included. Firmware is ordered and identified separately via the controller type plate.

Technical Specifications

Product Type
Control Unit

Slots
4

Slot One
Safety Module with Safe Torque Off

Wire Type
Stranded Copper Wire

Wire Size
0.25 to 0.5 mm2

Interface
D-sub Female 9-pin Interface

Slot Two
Digital I/O Extension Module

Input Number
16

Output Number
16

Slot Three
Encoder IndraDyn Module

Slot Four
Encoder EnDat 2.1 Module

Control Panel Compatibility
Standard

Communication
Profibus Master

Firmware
Ordered Separately

Safety
Safety Module
