R911334759 (CSH01.1C-SE-EN2-NNN-MA1-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-NNN-MA1-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Rexroth control section R911334759 (CSH01.1C-SE-EN2-NNN-MA1-L2-S-NN-FW) is a digital servo motor control module engineered for precise industrial motion control in applications such as robotics, paper processing, and packaging. This unit features two analog outputs, supports SERCOS interface for master communication, and offers primary encoder connectivity through EnDat 2.1, 1 Vpp, or TTL. With an operating altitude up to 1000 meters and temperature up to 40°C, it measures 241 x 103 x 49.5 mm and carries an IP20 rating. The module supports 'Safe Torque Off' functionality (SIL3/cat. 3 PL e), includes an analog I/O extension, and operates at up to 90% relative humidity without condensation. It requires authorized firmware for operation and utilizes the H1 connection point.

Technical Specifications

Max Elevation
1000 meters above sea level

Max Temperature
+40 degrees Celsius

Communication Interface
SERCOS

Firmware
Requires official firmware

Unit Size
241mm x 103mm x 49.5mm

Relative Humidity
up to 90%, no condensation

Protection
IP20 category

Connection Point
H1

Safety Feature
Safe Torque Off (SIL3/ cat. 3 PL e)

Input/Output Ports
analog I/O extension

Shipping
worldwide

Unit Protection
From exposure to rain-water and moisture
