The R911335426 (CSH01.1C-SE-ENS-EN1-NNN-S2-S-XP-FW) is a Bosch Rexroth control unit engineered for demanding industrial applications such as paper processing, printing, textile, and food machinery. Measuring 103 mm x 241 mm x 49.5 mm, it is suitable for installation at elevations up to 1000 meters. The CSH01.1C control section integrates with a compatible power section to form a digital drive controller capable of operating AC servo motors with high speed and resolution. Key features include two analog outputs, SERCOS interface as master communication, primary encoder support for Indradyn, Hiperface, 1 Vpp, and TTL, as well as digital input and output ports. The unit meets IP20 protection standards and incorporates a standard control panel for system integration. Firmware is required prior to use and must be obtained separately.

Technical Specifications

Product Type
Control Unit

Physical Dimensions
103mm x 241mm x 49.5mm

Permissible Elevation Mounting
1000 meters above sea level

Input/Output Ports
Digit Input and Output Ports

Protection Specifications
IP20

Additional Requirement
Installation of Firmware

Product Usage
Drive Controller for Modern Motors

Installation Recommendation
By a well-trained service technician

Installation Environment
Away from Rain and Water Jets
